DESCRIPTION




This is a two-dimensional cellular automata simulation on the surface of a sphere. The surface of the sphere is sectioned off into a number of triangular "cells". Each cell has three neighbors. Each cell can be either on, or off (alive or dead).

When the simulation first starts, a random half of the cells are turn on, or alive. The other half start in the off, or dead, state. When the simulation goes through one step, each cell looks at its own state and the state of its three neighbors and then either stays in its current state or changes state.



CONTROLS AND FEEDBACK



The sphere will automatically rotate to display the state of the cellular automata on its surface. The lighter patches are in the on or alive state, the darker, transparent patches are in the off or dead state.

Clicking the word "Step" will cause the CA to go through a number of rule iterations. The number of steps can be changed. The rules each cell follows can also be changed. The "Live Rules" specify how many alive neighbors an alive cell needs to stay alive in the next step. By default an alive cell needs 1 or 2 alive neighbors to stay alive in the next step. Correspondingly, if an alive cells has 0 or 3 alive neighbors it will die on the next step. The "Born Rules" specify how many alive neighbors a dead cell needs to become alive on the next step. By default a dead cell needs 2 alive neighbors to become alive on the next step. If a dead cells has 0,1 or 3 alive neighbors it will remain dead. Rules can be changed and must be specified in the format [n1, n2...n]. The number can range from 0 to 3, because each cell can have from 0 to 3 alive neighbors.

After changing the rules the simulation must be restarted by clicking on "Restart". This will redraw a new sphere with half of the cells alive. Clicking "Step" will then execute the new rules.
